Metal Cutting machine
this machine is mainly used for cutting metal coil leveling into strip and then cut to laminations.
The cutting material: silicon steel, CRGO, cold roll steel, galvanized steel, PPGI, SPTE, Tin plate Stainless steel, aluminum and copper steel etc.
It is of compact and reasonable structure, high automation, high precision and high efficiency.
Detailed introduction
Model
HJ-1500 NC shear machine
Model: HJ-1000/1300/1500
Introduction and Usage
this machine is mainly used for cutting metal coil leveling into strip and then cut to laminations.
The cutting material: silicon steel, CRGO, cold roll steel, galvanized steel, PPGI, SPTE, Tin plate Stainless steel, aluminum and copper steel etc.
It is of compact and reasonable structure, high automation, high precision and high efficiency.
Specification
Cutting length: 10mm-5000mm
Suitable strip width: 20mm-1500mm
Suitable thickness: 0.8-4.0mm
Cut-to-length precision: +-0.3mm
Cutting angle precision: ax 0.05degree
Cutting burr height: Max0.05mm
Cutting speed: 2000-20000impulse/second, adjustable based on feeding length
Max coil (material) weight: 5-8ton
Characteristics
1. Cutting: adopts motor hydraulic driven technology, big cutting force, high speed, low noise, long life.
2. Leveling: 11-roller leveling driven by big torque AC servo motor.
3. Feeding: driven by big torque AC servo motor, combined with leveling unit, quick response, high precision, positioning, low noise, small thermal braking, and long life.
4. Motion control: by advanced PLC, HMI operation, simple and convenient.
5. Life assurance: imported world famous linear guide and ball screw, high precious milling parts and high precision assembly, extend life of the machine.
