CRGO Slitting machine
Slitting machine,the configuration of the sensor, length measuring device, intelligent digital display meter, the cutting length that required can be preset,(unit precision:0.1m) sound alarm when reaching the number.
Detailed introduction
Steel slitting Machine --Features:
The line is suitable for kinds of CRGO, Silicon steel coil, cold rolled steel strip, hot rolled plates, galvanized strip, color coated plates, stainless steel, tinplate etc.
1. Thickness of roll slitting silicon steel sheet or low carbon steel sheet: 0.2~0.5mm
2. Width of the rolling slitting sheet: 40~1250mm
3 .Slitting Strip Burr:≦0.02mm
4 .Width tolerance of strip burr:≦±0.2mm
5. Speed of slitting line: 0~70M/min
6.Decoiler drum standard diameter:Φ500mm
7.Recoiler drum standard diameter:Φ500mm
8. Max load capacity of Decoiler : ≦6T
9. Total length: 11m, width 5m, covereing the area of 55 square meters.
10. Total weight: 11tons
11. Hight of the production line: 1m
Steel Slitting Machine --Lists of Main Equipments
(1) 6Ton Hydraulic pressing decoiler
(2) 6Ton hydraulic pressing recoiler
(3) Variable frequency roll slitting machine
(4) Double pneumatic guide pressing device
(5) 6Ton new type electric feed-in and feed-out lifting car
(6) Electric control panel
(7) Hydraulic station
(8) Grinding machine
(9) YG20 carbide scissors
The configuration of the sensor, length measuring device, intelligent digital display meter, the cutting length that required can be preset,(unit precision:0.1m) sound alarm when reaching the number.
Steel slitting machine is cutting the C.R.G.O silicon steel into strip,
for producing the silicon steel lamination for transformer core.
